Suzhou MobyData Smart System Co. Ltd.
Verified Supplier
1 Years
| Sign In | Join Free | My himfr.com |
|
1 Years
| Ask Lasest Price | |
| Brand Name : | MobyData |
| Model Number : | E3100 |
| Certification : | China Certification, CE |
| Price : | TBD |
| Payment Terms : | T/T |
| Supply Ability : | 20K pcs per Month |
| Delivery Time : | 7wks days < MOQ500 |
Authorized decoding libraries by Datalogic
Application Area
Unique Product Characteristics
Product Size
| Mechanical | |
| Dimensions | 21.7mm x 10.4mm x 8.1mm |
| Weight | 2.1g |
| Electrical | |
| Input Voltage | VCC 3.3V, VCC 1.8V,VCC 2.8V |
| Interface | MIPI |
| Illumination | White LED |
| Aiming | Red Laser |
| Current Consumption | Less than 200mA |
| Environmental Specifications | |
| Temperature | Operating: -25°C to 50°C |
| Storage: -40°C to 85°C | |
| Humidity | 0 to 95% relative humidity, non-condensing,at 50°C(122°F) |
| Ambient Light | 0 lux to 100,000 lux |
| Shock Rating | Maximum withstand 2500g,gravitational acceleration |
| Performance Parameter | |
| Shutter | Global shutter |
| Sensor Resolution | 640x480 (E3100)；1080x1280 (E3150) |
| FOV | H22°x V17°(E3100) H39°x V29°(E3150) |
| Symbol Contrast | 15% minimum print contrast ratio |
| Motion Tolerance | 200 cm/s maximum, 100 cm/s typical |
| Scan Angles | Pitch: ±60°; Roll: ±180°; Yaw: ±60° |
| Min Resolution | 1D linear:3 mil |
| Data Matrix: 7.5 mil (E3100),5 mil (E3150) | |
| Symbologies | |
| 2D Codes | UCC Composite;Aztec;China Sensible Code;Datamatrix;DotCode; QRCode;Micro QRCode;OCR Code |
| 1D / Linear Codes | Code EAN/UPC;GS1DataBar(RSS-14);Code39;Code 128(GS1-128); Code ISBT 128;Code Standard 2of5;Compressed 2of5;Datalogic 2of5; Industrial 2of5;Interleaved 2of5 (l2of5);Matrix 2of5;Codabar;Code11 Code93;MSI;Plessey;BC412;ISSN |
| Postal Codes | Australian Post; British Post; China Post; IMB; Japanese Post; KIX Post; Korea Post; Planet Code; Postnet; Royal Mail Code |
| Stacked Codes | EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites |
| DOF | |
3.13 mil CODE39 5 mil CODE39 10 mil CODE39 20 mil CODE39 13 mil EAN13 10 mil Data Matrix 15 mil Data Matrix | E3100 150 mm - 220 mm 120 mm - 400 mm 100 mm - 600 mm 160 mm - 950 mm 150 mm - 600 mm 150 mm - 300 mm 100 mm - 400 mm |
3.13 mil CODE39 5 mil CODE39 10 mil CODE39 20 mil CODE39 13 mil EAN13 10 mil Data Matrix 15 mil Data Matrix | E3150 95 mm - 270 mm 40 mm - 420 mm 50 mm - 700 mm 120 mm - 900 mm 90 mm - 600 mm 50 mm - 320 mm 40 mm - 440 mm |
FAQ
1. Are you a manufacturer?
Yes, we are. As a professional manufacturer specializing in barcode scanners and
PDA terminals, we possess deep expertise in industrial design,
mainboard development, product testing, and full-scale production.
We enforce rigorous quality control across all operational
processes, ensuring our products consistently meet the highest
industry standards.
2. Will you provide free SDK for me?
Certainly
3. What is the warranty period for your products?
Our products come with a Min. 12-month warranty (starting from the date of shipment), excluding parts that are consumable.
4. What is your minimum order quantity (MOQ)?
The standard MOQ for stock products is 1 unit. For OEM/ODM
projects, please provide your detailed requirements (e.g.,
customization scope, specifications), and we will advise the
corresponding MOQ based on your needs.
5. Is it possible to obtain a free sample?
While we do not offer free samples, we welcome you to purchase a
single sample unit for testing and evaluation.
6. Do you accept payments via PayPal?
No
7. How long is the delivery time?
For sample orders, we usually dispatch within 2-3 working days
after payment has been confirmed. For bulk orders, the lead time
may vary from 1 to 4 weeks, depending on the exact quantity
required.
8. What shipping methods do you use for delivery?
DHL, UPS, TNT, FEDEX, Aramex, EMS, and E-packing, or arrange the
collection of goods yourself.
9. Could you describe your after-sales service?
a. All products come with a minimum 12-month warranty (extendable for
certain
components), covering manufacturing defects and non-consumable parts.
b. We maintain a large inventory of genuine spare parts to ensure prompt replacement or repair of service requests, minimizing downtime for your operations.
c. Our team of certified engineers provides 24/7 online support (via phone, email, or remote access) to address troubleshooting, software updates, and operational guidance.
d. For complex issues, we can offer on-site service support (subject to regional availability) and customized maintenance plans to meet your specific needs.
|
|
